Zemic BM8G
د.إ0
Stainless steel IP68 shear beam load cell
Hermetically sealed
Robust and wide mounting surface
Suitable for harsh environment
Current calibrated (SC-option)
Zemic BM8G Introduction
The Zemic BM8G shear beam load cell is a robust stainless steel weighing sensor developed for industrial weighing applications requiring high accuracy, long‑term stability, and resistance to harsh environmental conditions. Its hermetically sealed construction with IP68 protection ensures reliable operation in wet, dusty, and wash‑down environments.
The shear beam design of this loadcell combined with a wide and stable mounting surface makes the BM8G particularly suitable for heavy‑duty floor scales, platform scales, and process weighing systems.
Installation
The Zemic BM8G should be mounted on a flat, rigid, and level surface to ensure accurate load transfer and stable performance. The applied force must be introduced vertically to the load cell while avoiding lateral forces and torsional stress. For multi‑load‑cell systems, symmetrical installation is recommended to achieve uniform load distribution across all load cells.
Fixation bolts must be tightened according to the specified torque values for the selected capacity. The BM8G is compatible with dedicated mounting and accessory kits that help improve alignment, protect against lift‑off, and allow controlled horizontal movement.
Loading
The BM8G is available in capacities from 500 kg up to 10 t and is approved to OIML R60 accuracy classes C3 and C4, depending on the selected model. The rated output sensitivity is 2.0 mV/V, providing a stable and repeatable signal for precision weighing indicators.
With a maximum number of verification intervals up to 4000, low combined error, and excellent repeatability, the BM8G is suitable for both industrial and trade‑approved weighing systems. The load cell offers a safe overload of 150 %FS and an ultimate overload of 300 %FS, ensuring durability under demanding load conditions. Its stainless steel construction and wide operating temperature range support reliable performance in challenging industrial environments.
Applications
The Zemic BM8G is commonly used in floor scales, platform scales, hopper and silo weighing systems, industrial process weighing, and other heavy‑duty weighing equipment. Its shear beam design, high accuracy, and stainless steel construction make it particularly suitable for industrial environments where reliability and long service life are required.
Types of multi-base conveyor weighing, such as conveyor belt weighing, roller weighing, and production line controller weighing
Various types of ceiling weighing, such as fixed and mobile ceiling crane weighing, elevator and hoist weighing, slaughterhouse and slaughterhouse ceiling weighing, and medical equipment ceiling weighing.
Various types of batching and mixers weighing for asphalt factories, concrete factories, food industries, pharmaceutical industries and petrochemical industries.
Various types of weighing silos and tanks
Various types of weighing pallets and forklifts
Zemic BM8G Dimensions (mm)
Wiring
The Zemic BM8G shear beam load cell is supplied with a shielded industrial cable and uses a standard 4‑wire wiring configuration. The cable shield is not connected to the load cell element and should be grounded at the indicator side only.
4‑Wire Wiring
Red — Excitation (+)
Black — Excitation (–)
Green — Signal (+)
White — Signal (–)
Shield — Ground (indicator side)
Proper grounding of the cable shield helps reduce electrical noise and ensures stable signal transmission between the load cell and weighing indicator.
Zemic BM8G Standards
| Brand | Zemic |
|---|---|
| Type | Bending |
| Elemental Material | Stainless Steel |
| IP (Ingress Protection) | IP68 |
| Capacity | 0.5 t, 1 t, 10 t, 2 t, 5 t, 7.5 t |
| Accuracy Class | C3, C4 |
| Maximum Intervals | 3000, 4000 |
| Minimum Verification Interval | 10000, 15000 |
| Output Sensitivity | 2.0 ± 0.004 |
| Zero Balance | 2.0 |
| Input Resistance | 350 ± 3.5 |
| Output Resistance | 350 ± 3.5 |
| Excitation Voltage | 5 ~ 15 |
| Compensated Temperature | -10 ~+ 40 |
| Safe Overload | 150 |
| Ultimate Overload | 300 |
| Dimensions (mm) | 203.2/234.95 x 36.48/47.36/55 x 47.63/69.85 |
