zemic H9Z2
د.إ0
Nickel plated alloy steel IP67 shear beam load cell
Used on the hoist cable to monitor the weight lifted
Suitable for measuring rope extension force
Zemic H9Z2 Introduction
The Zemic H9Z2 load cell is a special load cell that is widely used in the weighing industry. H9Z2 load cell is a special load cell for measuring the tensile force created in the cable. The application of this load cell is such that the cable passes through the load cell and with its tension, the upward force is applied to the middle part of the load cell and in this way the tensile force of the cable is calculated. The material of this load cell is nickel plated alloy steel and has an IP67 protection standard which is washable.
Loading
Applications
Measurement of pressure or tension force such as force testing device
Zemic H9Z2 Dimensions (mm)
Wiring
Zemic H9Z2 Standards
| Brand |
Zemic |
|---|---|
| Type |
Other |
| Elemental Material |
Nickel plated steel |
| IP (Ingress Protection) |
IP67 |
| Capacity |
0.5 t ,1 t ,1.5 t ,10 t ,2 t ,2.5 t ,5 t |
| Accuracy Class |
G5 |
| Maximum Intervals |
200 |
| Output Sensitivity |
0.57 ± 0.02 (0.5t) / 0.8 ± 0.02 ( 1, 1.5, 2, 2.5, 5t) / 1.0 ± 0.02 (10t) |
| Zero Balance |
2.0 |
| Input Resistance |
370 ± 10 |
| Output Resistance |
350 ± 3.5 |
| Excitation Voltage |
5 ~ 12 |
| Compensated Temperature |
-10 ~+ 40 |
| Safe Overload |
150 |
| Ultimate Overload |
200 |
| Dimensions (mm) |
95 / 101 / 130 x 50 / 52 / 58 / 64 / x 40 / 43 / 48.5 / 55 |
