HBM-RTN
Click to enlarge
Home Products Load Cells Compression - Ring Type HBM RTN
HBM-RSCC
HBM RSCC د.إ0
Back to products
HBM-U2A
HBM U2A د.إ0
HBM

HBM RTN

د.إ0

Datasheet

Clear
Compare
Compare
Add to wishlist
Compare
SKU: N/A Category: Compression - Ring Type
Share:
  • Description
  • Additional information
  • Downloads
  • Reviews (0)
Description

HBM load cell RTN with advanced weighing technology is suitable for super heavy uploads. Also with minimum load cell verification level of 10000, RTN is strong and has high accuracy. RTN supports capacities from 1 Ton to 450 Tons. Circular strain gauges are RTN constituents, which makes the effects of transverse loads least. HBM RTN has IP68 which makes it resistant to water and dust. Also RTN has ATEX which makes it usable in explosive environments. Also with 4450 ohms input resistance, RTN uses less energy. HBM RTN has many applications specially in melting and casting industries.

Installation of HBM RTN:

There are many ways to install this load cell. This is the most popular way to install HBM RTN:

Installation-RSS

How to load HBM RTN:

Applications of HBM RTN:

Measuring pressure force or tension like input force testing device.

Types of weighing silos and tanks.

Different types of batching and mixers for asphalt factories, concrete factories, food industry.

Also pharmacology industry and petrochemical industry.

Different classes of  scales for example fixed or mobile scales. Also industrial scales, airport scaled and medical scales for animals.

Variety of heavy weighbridges like trailer scales, trunk scales and train scales.

Physical form of HBM RTN:

Dimenssion-RTN

Wiring of HBM RTN:

Additional information
Brand

HBM

Capacity

1.0t, 100t, 10t, 150t, 15t, 2.0t, 220t, 22t, 330t, 33t, 4.7t, 470t, 47t, 68t

Class

C3

Material

Stainless Steel

Options

Standard

Downloads

Downloads

HBM-RTN.pdf

Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “HBM RTN” Cancel reply
