Celltec-PAL2
Click to enlarge
Home Products Load Cells Single Point - Platform Celltec PAL2
Celltec-PAL1B
Celltec PAL1B د.إ0
Back to products
Celltec-PAL3
Celltec PAL3 د.إ0
Celltec

Celltec PAL2

د.إ0

Datasheet

Clear
Compare
Compare
Add to wishlist
Compare
SKU: N/A Category: Single Point - Platform
Share:
  • Description
  • Additional information
  • Downloads
  • Reviews (0)
Description

Celltec load cell PAL2 is a single point load cells With 4 screws on its top and bottom. Due to its range of measurement, scale producers  use this load cell in commercial scales in capacity range of 75 kg to 1000 kg. PAL2. To load this load cell you need a wide upload plate. It does not require latten in time of installation because it has edge force support on its top and bottom.

Celltec load cell PAL2 is a single point load cell. The producer calibrates it and determines its accuracy class as “C3”. With size of 80×80 centimeters it has no weight difference to its edges.

This load cell is made of aluminum alloy and resistant glue fills its meeting point in resin method. It also has IP65 certification which makes it usable in industrial environments.

Installation of Celltec PAL2:

PAL2 is a single point load cell and its installation routine is in the picture:

Installation-PAL1B

How to load Celltec PAL2:

Applications of Celltec PAL2:

Variety of single point scales like retail and general scales, piece counter scales, postal scales, airport scales. Also it has application in home scales, label scales, barcode reader scales and industrial scales.

Variety of conveyor weighing in single point form like weighing conveyor, weighing rollers, production line controllers and variety of packing and filling machines.

Variety of hoper weighing for food and chemical industry.

Physical form of Celltec PAL2:



Dimensions-PAL2

Wiring of Celltec PAL2:

6Wire-2

Additional information
Brand

Celltec

Capacity

1.0t, 150kg, 250kg, 500kg, 635kg, 75kg

Class

C3, C4

Material

Alloy Steel

Options

Standard

Downloads

Downloads

Celltec-PAL2.pdf
