Revere-VT300
Click to enlarge
Home Products Electronics Weighing Indicators Revere VT300
Revere-VT200
Revere VT200 د.إ0
Back to products
Revere-VT400
Revere VT400 د.إ0
Vishay

Revere VT300

د.إ0

Datasheet

Specially designed as a weighbridge terminal

Large, 16-character LCD display

27 key alphanumeric and functions keyboard

Up to two serial ports with printing and networking (one standard)

Two opto-isolated weight setpoints

Alibi (Flash) memory and programmable database of transaction records

Real-time clock

Stainless steel enclosure (IP65),

aluminum enclosure (IP40)

Weighing and counting operating modes

OIML R-76 approved to 10000d

Clear
Compare
Compare
Add to wishlist
Compare
SKU: N/A Category: Weighing Indicators
Share:
  • Description
  • Additional information
  • Downloads
  • Reviews (0)
Description

Introduction of Vishay-Revere VT-300:

Vishay-Revere VT-300 is a weight indicator. VT-300 has high quality and accurate function. This indicator also uses a new technology for A/D named Sigma/Delta which has high speed and uses low voltage. VT-300 ha 16 characters LCD with backlight and height of 14.5 Mm. It also has 27 automatic keys on its keyboard for data entry and to calibrate. Calibration of this indicator is with load cells output results or uploading weight.

VT-300

Technical Information of Vishay-Revere VT-300:

VT-300 can connect to up to 10 load cells with 350 ohms resistance. It also has 2 serial ports (RS485 & RS232) to connect to other devices. The material of VT-300 body is stainless steel. VT-300 also has IP56. One other feature of this device is that it can save all day weightings up to 10000 weight measurements. It saves info in alibi memory. VT-300 also gives the user the ability to manage weightings with filters like customers, product type and trucks ID.

Applications of Vishay-Revere VT-300:

Variety of heavy or light weighbridges like trailer scales, trunk scales, fixed or mobile and with or without ramps.

Variety of single point scales like retail and general scales, piece counter scales, postal scales, airport scales. Also it has application in home scales, label scales, barcode reader scales and industrial scales.

Wiring of Vishay-Revere VT-300:

Wiring-VT300

Vishay-Revere VT-300 standards:

NTEP   CE   OIML
